Sliding Door Buffer Frame HT-5015
| Item | Content |
|---|---|
| Working temperature | -45℃~+50℃ |
| Run time | 2-5s |
| Working speed | ＜=0.5m/s |
| The maximum bearing | 50kgs |
| Service | more 80,000 times |
| Product scope | Suitable for sliding door,drawer,cabinets,etc To close the door to the effect of light and peace |
Types:
ltem No. 5015 Material POM
Details:
1. Piston rod adopts 25# carbon steel and 304 stainless steel solid rod, with chrome-plated surface and QBQ high-temperature nitriding treatment; smooth and non-stuck;
2. The tube body is made of 65Mn carbon steel, which is the high-density seamless steel tube, and the outer surface is plated with nickel to prevent air leakage and rust;
3. The production process of imported silicone oil and spacer is adopted to prevent oil leakage and air leakage, and the service life is more durable, reaching 100,000 times;
4. A variety of connectors can be selected; and can be customized, according to the specific requirements of the specific product then customizing connector colo,r size and style.
